Table 5-3. TZ4n Connections for ePWMx Modules
ePWMx Control for TZ4n = Control for TZ4n = not(EQEP1ERR) Control for TZ4n = not(EQEP2ERR)
not(EQEP1ERR OR
EQEP2ERR)
ePWM1 PINMMR41[0] = 1 PINMMR41[0] = 0 AND PINMMR41[1] PINMMR41[0] = 1 AND PINMMR41[1] = 0 AND
= 1 PINMMR41[2] = 1
ePWM2 PINMMR41[8] PINMMR41[8] = 0 AND PINMMR41[9] PINMMR41[8] = 1 AND PINMMR41[9] = 0 AND
= 1 PINMMR41[10] = 1
ePWM3 PINMMR41[16] PINMMR41[16] = 0 AND PINMMR41[16] = 1 AND PINMMR41[17] = 0
PINMMR41[17] = 1 AND PINMMR41[18] = 1
ePWM4 PINMMR41[24] PINMMR41[24] = 0 AND PINMMR41[24] = 1 AND PINMMR41[25] = 0
PINMMR41[25] = 1 AND PINMMR41[26] = 1
ePWM5 PINMMR42[0] PINMMR42[0] = 0 AND PINMMR42[1] PINMMR42[0] = 1 AND PINMMR42[1] = 0 AND
= 1 PINMMR42[2] = 1
ePWM6 PINMMR42[8] PINMMR42[8] = 0 AND PINMMR42[9] PINMMR42[8] = 1 AND PINMMR42[9] = 0 AND
= 1 PINMMR42[10] = 1
ePWM7 PINMMR42[16] PINMMR42[16] = 0 AND PINMMR42[16] = 1 AND PINMMR42[17] = 0
PINMMR42[17] = 1 AND PINMMR42[18] = 1
5.1.6.3 Trip Zone TZ5n
This trip zone input is dedicated to a clock failure on the device. That is, this trip zone input is asserted
whenever an oscillator failure or a PLL slip is detected on the device. The application can use this trip
zone input for each ePWMx module in order to prevent the external system from going out of control when
the device clocks are not within expected range (system running at limp clock).
The oscillator failure and PLL slip signals used for this trip zone input are taken from the status flags in the
system module. These are level signals are set until cleared by the application.
5.1.6.4 Trip Zone TZ6n
This trip zone input to the ePWMx modules is dedicated to a debug mode entry of the CPU. If enabled,
the user can force the PWM outputs to a known state when the emulator stops the CPU. This prevents the
external system from going out of control when the CPU is stopped.
5.1.7 Triggering of ADC Start of Conversion Using ePWMx SOCA and SOCB Outputs
A special scheme is implemented in order to select the actual signal used for triggering the start of
conversion on the two ADCs on this device. This scheme is defined in Section 5.4.2.3.
5.1.8 Enhanced Translator-Pulse Width Modulator (ePWMx) Timings
Table 5-4. ePWMx Timing Requirements
PARAMETER TEST CONDITIONS MIN MAX UNIT
t
w(SYNCIN)
Synchronization input pulse width Asynchronous 2 t
c(VCLK4)
cycles
Synchronous 2 t
c(VCLK4)
cycles
Synchronous, with input 2 t
c(VCLK4)
+ filter width cycles
filter
Table 5-5. ePWMx Switching Characteristics
PARAMETER TEST CONDITIONS MIN MAX UNIT
t
w(PWM)
Pulse duration, ePWMx output high or low 33.33 ns
t
w(SYNCOUT
Synchronization Output Pulse Width 8 t
c(VCLK4)
cycles
)
t
d(PWM)tza
Delay time, trip input active to PWM forced high, no pin load 25 ns
OR Delay time, trip input active to PWM forced
low
120 Peripheral Information and Electrical Specifications Copyright © 2012, Texas Instruments Incorporated
