RM46L852
www.ti.com
SPNS185 –SEPTEMBER 2012
Table 5-5. ePWMx Switching Characteristics (continued)
PARAMETER TEST CONDITIONS MIN MAX UNIT
t
d(TZ-
Delay time, trip input active to PWM Hi-Z 20 ns
PWM)HZ
Table 5-6. ePWMx Trip-Zone Timing Requirements
PARAMETER TEST CONDITIONS MIN MAX UNIT
t
w(TZ)
Pulse duration, TZn input low Asynchronous 2 * TBePWMx cycles
Synchronous 2 tc(VCLK4) cycles
Synchronous, with input 2 tc(VCLK4) + filter cycles
filter width
