PRODUCTPREVIEW
RM46L852
SPNS185 –SEPTEMBER 2012
www.ti.com
2.3.1.21 Ground Reference for All Supplies Except VCCAD
Table 2-24. PGE Ground Reference for All Supplies Except VCCAD
Terminal Signal Default Pull Type Description
Type Pull State
Signal Name 144
PGE
VSS 11 Ground - - Ground reference
VSS 21
VSS 27
VSS 28
VSS 43
VSS 44
VSS 47
VSS 50
VSS 56
VSS 88
VSS 102
VSS 103
VSS 115
VSS 121
VSS 122
VSS 135
VSS 138
VSS 144
24 Device Package and Terminal Functions Copyright © 2012, Texas Instruments Incorporated
Submit Documentation Feedback
