RM46L852
www.ti.com
SPNS185 –SEPTEMBER 2012
2.3.1.19 Supply for Core Logic: 1.2V nominal
Table 2-22. PGE Supply for Core Logic: 1.2V nominal
Terminal Signal Default Pull Type Description
Type Pull State
Signal Name 144
PGE
VCC 17 1.2V - - Core supply
Power
VCC 29
VCC 45
VCC 48
VCC 49
VCC 57
VCC 87
VCC 101
VCC 114
VCC 123
VCC 137
VCC 143
2.3.1.20 Supply for I/O Cells: 3.3V nominal
Table 2-23. PGE Supply for I/O Cells: 3.3V nominal
Terminal Signal Default Pull Type Description
Type Pull State
Signal Name 144
PGE
VCCIO 10 3.3V - - Operating supply for I/Os
Power
VCCIO 26
VCCIO 42
VCCIO 104
VCCIO 120
VCCIO 136
Copyright © 2012, Texas Instruments Incorporated Device Package and Terminal Functions 23
Submit Documentation Feedback
