PRODUCTPREVIEW
RM46L852
www.ti.com SPNS185 –SEPTEMBER 2012
Table 2-41. ZWT USB Device Port Controller Interface (USB_FUNC) (continued)
Terminal Signal Default Pull Type Description
Type Pull State
Signal Name 337
ZWT
GIOB[3]/USB2.RCV/USB_FUNC.RXDI W10 Input Pull Down Fixed, 20uA USB device single-ended
data input
GIOA[1]/USB2.VM/USB_FUNC.RXDMI C2 USB device logic value of
D-minus
GIOA[0]/USB2.VP/USB_FUNC.RXDPI A5 USB device logic value of
D-plus
N2HET1[22]/USB2.TXSE0/USB_FUNC.SE0O B3 Output Pull Down - USB device single-ended
zero
N2HET1[09]/N2HET2[16]/USB2.SUSPEND/USB_FUNC.SUS V7 USB device suspend
PENDO/EPWM7A output
GIOA[2]/USB2.TXDAT/USB_FUNC.TXDO/N2HET2[0]/EQEP C1 USB device transmit data
2I
N2HET1[11]/MIBSPI3NCS[4]/N2HET2[18]/ E3 Input Pull Down Fixed, 20uA USB device power
USB2.OverCurrent/USB_FUNC.VBUSI/EPWM1SYNCO connected
Copyright © 2012, Texas Instruments Incorporated Device Package and Terminal Functions 37
