PRODUCTPREVIEW
RM46L852
www.ti.com
SPNS185 SEPTEMBER 2012
Table 2-42. External Memory Interface (EMIF) (continued)
Terminal Signal Default Pull Type Description
Type Pull State
Signal Name 337
ZWT
EMIF_DATA[0] K15 I/O Pull Up Fixed, 20uA EMIF Data
EMIF_DATA[1] L15 I/O
EMIF_DATA[2] M15 I/O
EMIF_DATA[3] N15 I/O
EMIF_DATA[4] E5 I/O
EMIF_DATA[5] F5 I/O
EMIF_DATA[6] G5 I/O
EMIF_DATA[7] K5 I/O
EMIF_DATA[8] L5 I/O
EMIF_DATA[9] M5 I/O
EMIF_DATA[10] N5 I/O
EMIF_DATA[11] P5 I/O
EMIF_DATA[12] R5 I/O
EMIF_DATA[13] R6 I/O
EMIF_DATA[14] R7 I/O
EMIF_DATA[15] R8 I/O
Copyright © 2012, Texas Instruments Incorporated Device Package and Terminal Functions 39
Submit Documentation Feedback
