Texas Instruments TMS320C6748 User Manual

15
TMS320C6748
www.ti.com SPRS590G –JUNE 2009–REVISED JANUARY 2017
Submit Documentation Feedback
Product Folder Links: TMS320C6748
Device ComparisonCopyright © 2009–2017, Texas Instruments Incorporated
Table 3-3. C674x L1/L2 Memory Protection Registers (continued)
HEX ADDRESS RANGE REGISTER ACRONYM DESCRIPTION
0x0184 A200 L2MPPA0
L2 memory protection page attribute register 0 (controls memory address
0x0080 0000 - 0x0080 1FFF)
0x0184 A204 L2MPPA1
L2 memory protection page attribute register 1 (controls memory address
0x0080 2000 - 0x0080 3FFF)
0x0184 A208 L2MPPA2
L2 memory protection page attribute register 2 (controls memory address
0x0080 4000 - 0x0080 5FFF)
0x0184 A20C L2MPPA3
L2 memory protection page attribute register 3 (controls memory address
0x0080 6000 - 0x0080 7FFF)
0x0184 A210 L2MPPA4
L2 memory protection page attribute register 4 (controls memory address
0x0080 8000 - 0x0080 9FFF)
0x0184 A214 L2MPPA5
L2 memory protection page attribute register 5 (controls memory address
0x0080 A000 - 0x0080 BFFF)
0x0184 A218 L2MPPA6
L2 memory protection page attribute register 6 (controls memory address
0x0080 C000 - 0x0080 DFFF)
0x0184 A21C L2MPPA7
L2 memory protection page attribute register 7 (controls memory address
0x0080 E000 - 0x0080 FFFF)
0x0184 A220 L2MPPA8
L2 memory protection page attribute register 8 (controls memory address
0x0081 0000 - 0x0081 1FFF)
0x0184 A224 L2MPPA9
L2 memory protection page attribute register 9 (controls memory address
0x0081 2000 - 0x0081 3FFF)
0x0184 A228 L2MPPA10
L2 memory protection page attribute register 10 (controls memory address
0x0081 4000 - 0x0081 5FFF)
0x0184 A22C L2MPPA11
L2 memory protection page attribute register 11 (controls memory address
0x0081 6000 - 0x0081 7FFF)
0x0184 A230 L2MPPA12
L2 memory protection page attribute register 12 (controls memory address
0x0081 8000 - 0x0081 9FFF)
0x0184 A234 L2MPPA13
L2 memory protection page attribute register 13 (controls memory address
0x0081 A000 - 0x0081 BFFF)
0x0184 A238 L2MPPA14
L2 memory protection page attribute register 14 (controls memory address
0x0081 C000 - 0x0081 DFFF)
0x0184 A23C L2MPPA15
L2 memory protection page attribute register 15 (controls memory address
0x0081 E000 - 0x0081 FFFF)
0x0184 A240 L2MPPA16
L2 memory protection page attribute register 16 (controls memory address
0x0082 0000 - 0x0082 1FFF)
0x0184 A244 L2MPPA17
L2 memory protection page attribute register 17 (controls memory address
0x0082 2000 - 0x0082 3FFF)
0x0184 A248 L2MPPA18
L2 memory protection page attribute register 18 (controls memory address
0x0082 4000 - 0x0082 5FFF)
0x0184 A24C L2MPPA19
L2 memory protection page attribute register 19 (controls memory address
0x0082 6000 - 0x0082 7FFF)
0x0184 A250 L2MPPA20
L2 memory protection page attribute register 20 (controls memory address
0x0082 8000 - 0x0082 9FFF)
0x0184 A254 L2MPPA21
L2 memory protection page attribute register 21 (controls memory address
0x0082 A000 - 0x0082 BFFF)
0x0184 A258 L2MPPA22
L2 memory protection page attribute register 22 (controls memory address
0x0082 C000 - 0x0082 DFFF)
0x0184 A25C L2MPPA23
L2 memory protection page attribute register 23 (controls memory address
0x0082 E000 - 0x0082 FFFF)
0x0184 A260 L2MPPA24
L2 memory protection page attribute register 24 (controls memory address
0x0083 0000 - 0x0083 1FFF)
0x0184 A264 L2MPPA25
L2 memory protection page attribute register 25 (controls memory address
0x0083 2000 - 0x0083 3FFF)
0x0184 A268 L2MPPA26
L2 memory protection page attribute register 26 (controls memory address
0x0083 4000 - 0x0083 5FFF)
0x0184 A26C L2MPPA27
L2 memory protection page attribute register 27 (controls memory address
0x0083 6000 - 0x0083 7FFF)
