20
TMS320C6748
SPRS590G –JUNE 2009–REVISED JANUARY 2017
www.ti.com
Submit Documentation Feedback
Product Folder Links: TMS320C6748
Device Comparison Copyright © 2009–2017, Texas Instruments Incorporated
(1) The DSP L2 ROM is used for boot purposes and cannot be programmed with application code
3.4 Memory Map Summary
Note: Read/Write accesses to illegal or reserved addresses in the memory map may cause undefined
behavior.
Table 3-4. C6748 Top Level Memory Map
Start Address End Address Size DSP Mem Map EDMA Mem Map PRUSS Mem Map Master
Peripheral Mem
Map
LCDC
Mem Map
0x0000 0000 0x0000 0FFF 4K PRUSS Local
Address Space
0x0000 1000 0x006F FFFF
0x0070 0000 0x007F FFFF 1024K DSP L2 ROM
(1)
0x0080 0000 0x0083 FFFF 256K DSP L2 RAM
0x0084 0000 0x00DF FFFF
0x00E0 0000 0x00E0 7FFF 32K DSP L1P RAM
0x00E0 8000 0x00EF FFFF
0x00F0 0000 0x00F0 7FFF 32K DSP L1D RAM
0x00F0 8000 0x017F FFFF
0x0180 0000 0x0180 FFFF 64K DSP Interrupt
Controller
0x0181 0000 0x0181 0FFF 4K DSP Powerdown
Controller
0x0181 1000 0x0181 1FFF 4K DSP Security ID
0x0181 2000 0x0181 2FFF 4K DSP Revision ID
0x0181 3000 0x0181 FFFF 52K
0x0182 0000 0x0182 FFFF 64K DSP EMC
0x0183 0000 0x0183 FFFF 64K DSP Internal
Reserved
0x0184 0000 0x0184 FFFF 64K DSP Memory
System
0x0185 0000 0x01BF FFFF
0x01C0 0000 0x01C0 7FFF 32K EDMA3 CC
0x01C0 8000 0x01C0 83FF 1K EDMA3 TC0
0x01C0 8400 0x01C0 87FF 1K EDMA3 TC1
0x01C0 8800 0x01C0 FFFF
0x01C1 0000 0x01C1 0FFF 4K PSC 0
0x01C1 1000 0x01C1 1FFF 4K PLL Controller 0
0x01C1 2000 0x01C1 3FFF
0x01C1 4000 0x01C1 4FFF 4K SYSCFG0
0x01C1 5000 0x01C1 FFFF
0x01C2 0000 0x01C2 0FFF 4K Timer0
0x01C2 1000 0x01C2 1FFF 4K Timer1
0x01C2 2000 0x01C2 2FFF 4K I2C 0
0x01C2 3000 0x01C2 3FFF 4K RTC
0x01C2 4000 0x01C3 FFFF
0x01C4 0000 0x01C4 0FFF 4K MMC/SD 0
0x01C4 1000 0x01C4 1FFF 4K SPI 0
0x01C4 2000 0x01C4 2FFF 4K UART 0
0x01C4 3000 0x01CF FFFF
0x01D0 0000 0x01D0 0FFF 4K McASP 0 Control
0x01D0 1000 0x01D0 1FFF 4K McASP 0 AFIFO Ctrl
