92
TMS320C6748
SPRS590G –JUNE 2009–REVISED JANUARY 2017
www.ti.com
Submit Documentation Feedback
Product Folder Links: TMS320C6748
Peripheral Information and Electrical Specifications Copyright © 2009–2017, Texas Instruments Incorporated
6.7 Interrupts
The device has a large number of interrupts to service the needs of its many peripherals and subsystems.
6.7.1 DSP Interrupts
The C674x DSP interrupt controller combines device events into 12 prioritized interrupts. The source for
each of the 12 CPU interrupts is user programmable and is listed in Table 6-6. Also, the interrupt
controller controls the generation of the CPU exceptions, NMI, and emulation interrupts. Table 6-7
summarizes the C674x interrupt controller registers and memory locations.
Refer to the C674x DSP MegaModule Reference Guide (SPRUFK5) and the TMS320C674x DSP CPU
and Instruction Set Reference Guide (SPRUFE8) for details of the C674x interrupts.
Table 6-6. C6748 DSP Interrupts
EVT# Interrupt Name Source
0 EVT0 C674x Int Ctl 0
1 EVT1 C674x Int Ctl 1
2 EVT2 C674x Int Ctl 2
3 EVT3 C674x Int Ctl 3
4 T64P0_TINT12 Timer64P0 - TINT12
5 SYSCFG_CHIPINT2 SYSCFG CHIPSIG Register
6 PRU_EVTOUT0 PRUSS Interrupt
7 EHRPWM0 HiResTimer/PWM0 Interrupt
8 EDMA3_0_CC0_INT1 EDMA3_0 Channel Controller 0 Shadow Region 1 Transfer
Completion Interrupt
9 EMU_DTDMA C674x-ECM
10 EHRPWM0TZ HiResTimer/PWM0 Trip Zone Interrupt
11 EMU_RTDXRX C674x-RTDX
12 EMU_RTDXTX C674x-RTDX
13 IDMAINT0 C674x-EMC
14 IDMAINT1 C674x-EMC
15 MMCSD0_INT0 MMCSD0 MMC/SD Interrupt
16 MMCSD0_INT1 MMCSD0 SDIO Interrupt
17 PRU_EVTOUT1 PRUSS Interrupt
18 EHRPWM1 HiResTimer/PWM1 Interrupt
19 USB0_INT USB0 Interrupt
20 USB1_HCINT USB1 OHCI Host Controller Interrupt
21 USB1_RWAKEUP USB1 Remote Wakeup Interrupt
22 PRU_EVTOUT2 PRUSS Interrupt
23 EHRPWM1TZ HiResTimer/PWM1 Trip Zone Interrupt
24 SATA_INT SATA Controller
25 T64P2_TINTALL Timer64P2 Combined TINT12 and TINT 34 Interrupt
26 EMAC_C0RXTHRESH EMAC - Core 0 Receive Threshold Interrupt
27 EMAC_C0RX EMAC - Core 0 Receive Interrupt
28 EMAC_C0TX EMAC - Core 0 Transmit Interrupt
29 EMAC_C0MISC EMAC - Core 0 Miscellaneous Interrupt
30 EMAC_C1RXTHRESH EMAC - Core 1 Receive Threshold Interrupt
31 EMAC_C1RX EMAC - Core 1 Receive Interrupt
32 EMAC_C1TX EMAC - Core 1 Transmit Interrupt
33 EMAC_C1MISC EMAC - Core 1 Miscellaneous Interrupt
34 UHPI_DSPINT UHPI DSP Interrupt
To Next Page
