8 Mechanical Packaging and Orderable Information
This section describes the orderable part numbers, packaging options, materials, thermal and mechanical
parameters.
8.1 Thermal Data for ZCE Package
The following table shows the thermal resistance characteristics for the PBGA–ZCE mechanical package.
Table 8-1. Thermal Resistance Characteristics (PBGA Package) [ZCE]
NO. °C/W
(1)
AIR FLOW (m/s)
(2)
1 RΘ
JC
Junction-to-case 7.6 N/A
2 RΘ
JB
Junction-to-board 11.3 N /A
3 RΘ
JA
Junction-to-free air 23.9 0.00
4
RΘ
JMA
Junction-to-moving air
21.2 0.50
5 20.3 1.00
6 19.5 2.00
7 18.6 4.00
8
Psi
JT
Junction-to-package top
0.2 0.00
9 0.3 0.50
10 0.3 1.00
11 0.4 2.00
12 0.5 4.00
13
Psi
JB
Junction-to-board
11.2 0.00
14 11.1 0.50
15 11.1 1.00
16 11.0 2.00
17 10.9 4.00
