198

TMS320C6748

SPRS590G –JUNE 2009–REVISED JANUARY 2017

www.ti.com

Submit Documentation Feedback

Product Folder Links: TMS320C6748

Table 6-94. Ethernet Media Access Controller (EMAC) Registers (continued)

BYTE ADDRESS ACRONYM REGISTER DESCRIPTION

0x01E2 3654 TX5CP Transmit Channel 5 Completion Pointer Register

0x01E2 3658 TX6CP Transmit Channel 6 Completion Pointer Register

0x01E2 365C TX7CP Transmit Channel 7 Completion Pointer Register

0x01E2 3660 RX0CP Receive Channel 0 Completion Pointer Register

0x01E2 3664 RX1CP Receive Channel 1 Completion Pointer Register

0x01E2 3668 RX2CP Receive Channel 2 Completion Pointer Register

0x01E2 366C RX3CP Receive Channel 3 Completion Pointer Register

0x01E2 3670 RX4CP Receive Channel 4 Completion Pointer Register

0x01E2 3674 RX5CP Receive Channel 5 Completion Pointer Register

0x01E2 3678 RX6CP Receive Channel 6 Completion Pointer Register

0x01E2 367C RX7CP Receive Channel 7 Completion Pointer Register

Table 6-95. EMAC Statistics Registers

BYTE ADDRESS ACRONYM REGISTER DESCRIPTION

0x01E2 3200 RXGOODFRAMES Good Receive Frames Register

0x01E2 3204 RXBCASTFRAMES

Broadcast Receive Frames Register

(Total number of good broadcast frames received)

0x01E2 3208 RXMCASTFRAMES

Multicast Receive Frames Register

(Total number of good multicast frames received)

0x01E2 320C RXPAUSEFRAMES Pause Receive Frames Register

0x01E2 3210 RXCRCERRORS

Receive CRC Errors Register

(Total number of frames received with CRC errors)

0x01E2 3214 RXALIGNCODEERRORS

Receive Alignment/Code Errors Register

(Total number of frames received with alignment/code errors)

0x01E2 3218 RXOVERSIZED

Receive Oversized Frames Register

(Total number of oversized frames received)

0x01E2 321C RXJABBER

Receive Jabber Frames Register

(Total number of jabber frames received)

0x01E2 3220 RXUNDERSIZED

Receive Undersized Frames Register

(Total number of undersized frames received)

0x01E2 3224 RXFRAGMENTS Receive Frame Fragments Register

0x01E2 3228 RXFILTERED Filtered Receive Frames Register

0x01E2 322C RXQOSFILTERED Received QOS Filtered Frames Register

0x01E2 3230 RXOCTETS

Receive Octet Frames Register

(Total number of received bytes in good frames)

0x01E2 3234 TXGOODFRAMES

Good Transmit Frames Register

(Total number of good frames transmitted)

0x01E2 3238 TXBCASTFRAMES Broadcast Transmit Frames Register

0x01E2 323C TXMCASTFRAMES Multicast Transmit Frames Register

0x01E2 3240 TXPAUSEFRAMES Pause Transmit Frames Register

0x01E2 3244 TXDEFERRED Deferred Transmit Frames Register

0x01E2 3248 TXCOLLISION Transmit Collision Frames Register

0x01E2 324C TXSINGLECOLL Transmit Single Collision Frames Register

0x01E2 3250 TXMULTICOLL Transmit Multiple Collision Frames Register

0x01E2 3254 TXEXCESSIVECOLL Transmit Excessive Collision Frames Register

0x01E2 3258 TXLATECOLL Transmit Late Collision Frames Register

0x01E2 325C TXUNDERRUN Transmit Underrun Error Register

0x01E2 3260 TXCARRIERSENSE Transmit Carrier Sense Errors Register

0x01E2 3264 TXOCTETS Transmit Octet Frames Register

0x01E2 3268 FRAME64 Transmit and Receive 64 Octet Frames Register
