244
TMS320C6748
SPRS590G –JUNE 2009–REVISED JANUARY 2017
www.ti.com
Submit Documentation Feedback
Product Folder Links: TMS320C6748
Peripheral Information and Electrical Specifications Copyright © 2009–2017, Texas Instruments Incorporated
(1) These registers are only available on eHRPWM instances that include the high-resolution PWM (HRPWM) extension; otherwise, these
locations are reserved.
Table 6-125. eHRPWM Module Control and Status Registers Grouped by Submodule
eHRPWM0
BYTE ADDRESS
eHRPWM1
BYTE ADDRESS ACRONYM SHADOW REGISTER DESCRIPTION
Time-Base Submodule Registers
0x01F0 0000 0x01F0 2000 TBCTL No Time-Base Control Register
0x01F0 0002 0x01F0 2002 TBSTS No Time-Base Status Register
0x01F0 0004 0x01F0 2004 TBPHSHR No Extension for HRPWM Phase Register
(1)
0x01F0 0006 0x01F0 2006 TBPHS No Time-Base Phase Register
0x01F0 0008 0x01F0 2008 TBCNT No Time-Base Counter Register
0x01F0 000A 0x01F0 200A TBPRD Yes Time-Base Period Register
Counter-Compare Submodule Registers
0x01F0 000E 0x01F0 200E CMPCTL No Counter-Compare Control Register
0x01F0 0010 0x01F0 2010 CMPAHR No Extension for HRPWM Counter-Compare A Register
(1)
0x01F0 0012 0x01F0 2012 CMPA Yes Counter-Compare A Register
0x01F0 0014 0x01F0 2014 CMPB Yes Counter-Compare B Register
Action-Qualifier Submodule Registers
0x01F0 0016 0x01F0 2016 AQCTLA No Action-Qualifier Control Register for Output A (eHRPWMxA)
0x01F0 0018 0x01F0 2018 AQCTLB No Action-Qualifier Control Register for Output B (eHRPWMxB)
0x01F0 001A 0x01F0 201A AQSFRC No Action-Qualifier Software Force Register
0x01F0 001C 0x01F0 201C AQCSFRC Yes Action-Qualifier Continuous S/W Force Register Set
Dead-Band Generator Submodule Registers
0x01F0 001E 0x01F0 201E DBCTL No Dead-Band Generator Control Register
0x01F0 0020 0x01F0 2020 DBRED No Dead-Band Generator Rising Edge Delay Count Register
0x01F0 0022 0x01F0 2022 DBFED No Dead-Band Generator Falling Edge Delay Count Register
PWM-Chopper Submodule Registers
0x01F0 003C 0x01F0 203C PCCTL No PWM-Chopper Control Register
Trip-Zone Submodule Registers
0x01F0 0024 0x01F0 2024 TZSEL No Trip-Zone Select Register
0x01F0 0028 0x01F0 2028 TZCTL No Trip-Zone Control Register
0x01F0 002A 0x01F0 202A TZEINT No Trip-Zone Enable Interrupt Register
0x01F0 002C 0x01F0 202C TZFLG No Trip-Zone Flag Register
0x01F0 002E 0x01F0 202E TZCLR No Trip-Zone Clear Register
0x01F0 0030 0x01F0 2030 TZFRC No Trip-Zone Force Register
Event-Trigger Submodule Registers
0x01F0 0032 0x01F0 2032 ETSEL No Event-Trigger Selection Register
0x01F0 0034 0x01F0 2034 ETPS No Event-Trigger Pre-Scale Register
0x01F0 0036 0x01F0 2036 ETFLG No Event-Trigger Flag Register
0x01F0 0038 0x01F0 2038 ETCLR No Event-Trigger Clear Register
0x01F0 003A 0x01F0 203A ETFRC No Event-Trigger Force Register
High-Resolution PWM (HRPWM) Submodule Registers
0x01F0 1040 0x01F0 3040 HRCNFG No HRPWM Configuration Register
(1)
