Texi Fox 25
7
BOBBIN TENSION
TO CHECK:
The bobbin thread tension should be between 35~45g when pulling the
thread by a tension meter.
If it is not within the above limit, adjust as follows:
ADJUSTMENT PROCEDURE :
1. Turn the adjusting screw (C) in the direction of (B) when the bobbin thread
tension is too tight.
2. Turn the adjusting screw (C) in the direction of (A) when the bobbin thread
tension is too loose.
3. Recheck the bobbin tension.
MECHANICAL ADJUSTMENT
pic.2
B
A
Thread
pic.1
Tension meter
between 35~45g
C
To Next Page
