however
o Loading OBELISK top2 with TR 611 top2 program in TR 610 top2 is not possible
o Loading OBELISK top2 with TR 610 top2 program in another of the channels of a TR
612 top2 is not possible
"Channel crossing" via the software OBELISK top2:
o Examples:
The switching times from a TR 610 top2 are transferred to the C2 channel of a
TR 612 top2.
The switching times in the channel C2 of a TR 612 top2 are copied to a TR 611
top2.
From a TR 611 top2 only the switching times (not the pulse times and cycle
programs) are transferred to a TR 610 top2.
13.3 OBELISK menu
If an OBELISK top2 memory card is inserted the OBELISK top2 data are verified (this lasts for a few
seconds and is shown by a progress bar):
- If the OBELISK top2 does not match the time switch type OBELISK ERROR is shown on the time
switch display.
- Only the copying process TIME SWITCH OBELISK is still possible.
- When selecting other menu items in the OBELISK menu OBELISK ERROR is shown.
- If the OBELISK top2 and time switch do not match, the OBELISK menu is shown in the time switch
display:
COPYING OBELISK TIME SWITCH
continue with push button ► or execute
with OK
