Thermal Dynamics 81 CUTMASTER Service Manual

PARTS LISTS 6-6 Manual 0-2957
6.06 Rear Panel Replacement Parts
Item # Qty Description Ref. Catalog #
1 1 Assembly, Filter/Regulator 9-7514
2 1 Regulator/Filter Replacement Element 9-4414
3 1 Regulator Mounting Bracket 9-7589
4 Input Power Cable
1 for 208/230-Volt Units 9-8596
1 for 400-Volt Three-Phase units 9-8562
1 for 400-Volt and 415-Volt CE units 9-8553
1 for 460-Volt Three-Phase units 9-8593
1 for 600-Volt Three-Phase units 9-8593
5 1 Mounting Nut 9-5804
6 1 Pressure Gauge 9-1045
NOTE: Illustration may vary slightly from unit.
Art # A-03005
2
1
3
4
5
6
