2.05 Input Wiring Specications
CutMaster 58 Power Supply Input Cable Wiring Requirements
Input voltage Freq Power Input Suggested Sizes
Volts Hz kVA I max I
1
eff Fuse (amps)
Flexible Cord
(Min. AWG)
1 Phase
208 60 10.4 47 30 50 10
230 60 10.8 45 29 50 10
460 60 15.2 31 20 35 12
3 Phase
208 60 5.4 26 17 30 12
230 50/60 5.8 24 16 30 12
380 50/60 6.1 16 11 20 14
400 50/60 6.4 16 11 20 14
460 60 7.4 16 10 20 12
600 60 7.8 13 11 15 12
Line Voltages with Suggested Circuit Protection and Wire Sizes
Based on National Electric Code and Canadian Electric Code
NOTE!
Refer to Local and National Codes or local authority having jurisdiction for proper wiring require-
ments.
Cable size is de-rated based on the Duty Cycle of the equipment.
