CUTMASTER 58
Manual 0-5544 PARTS LIST
6-1
SECTION 6:
PARTS LISTS
6.01 Introduction
A. Parts List Breakdown
The parts list provide a breakdown of all replaceable components. The parts lists are arranged as follows:
6.03 Power Supply Replacement
6.04 Replacement Power Supply Parts
6.05 Options and Accessories
6.06 Replacement Parts for Hand Torch
6.07 Replacement Parts - for Machine Torches with Unshielded Leads
6.08 Replacement Shielded Machine Torch Leads Assemblies
6.09 Torch Consumable Parts (SL60)
6.10 Torch Consumable Parts (SL100)
NOTE!
Parts listed without item numbers are not shown, but may be ordered by the catalog number shown.
B. Returns
If a product must be returned for service, contact your distributor. Materials returned without proper authorization will not be
accepted.
6.02 Ordering Information
Order replacement parts by catalog number and complete description of the part or assembly, as listed in the parts list for each
type item. Also include the model and serial number of the power supply. Address all inquiries to your authorized distributor.
6.03 Power Supply Replacement
The following items are included with the replacement power supply: work cable & clamp, input power cable, gas pressure regula-
tor / filter, and operating manual.
Qty Description Catalog #
1 CutMaster
58 Power Supply
208/230 - 460VAC, Single or 3 Phase, 60Hz,
with input power cable and plug 3-5830-1
460VAC, Single or 3 Phase, 60Hz,
with input power cable 3-5830-2
600VAC, 3 Phase, 60Hz,
with input power cable 3-5830-5
6.04 Replacement Power Supply Parts
Qty Description Catalog #
1 Regulator 9-0115*
1 Filter Assembly Replacement Element 9-0116
1 Input Power Cord for 208/230 V Power Supply 8-4384
1 Input Power Cord for 460/600 V Power Supply 9-8593
