CUTMASTER 58
OPERATION Manual 0-5544
4T-12
Type Torch: SL60QD With Shielded Tip Type Material: Stainless Steel
Type Plasma Gas: Air Type Secondary Gas: Single Gas Torch
Thickness Tip Output Amperage
Speed (Per
Minute)
Standoff
Plasma Gas
Press
Flow (CFH) Pierce
Pierce
Height
Inches
mm
(Cat.
No.)
Volts
(VDC)
(Amps) Inches Meters Inches mm psi* bar Plasma Total**
Delay
(Sec)
Inches mm
0.036 0.9 9-8208 109 40 180 4.57 0.125 3.2 70 4.8 55 170 0.00 0.2 5.1
0.05 1.3 9-8208 105 40 165 4.19 0.125 3.2 70 4.8 55 170 0.00 0.2 5.1
0.06 1.5 9-8208 115 40 120 3.05 0.125 3.2 70 4.8 55 170 0.10 0.2 5.1
0.078 2.0 9-8208 120 40 65 1.65 0.187 4.8 70 4.8 55 170 0.30 0.2 5.1
0.135 3.4 9-8208 125 40 25 0.64 0.187 4.8 70 4.8 55 170 0.40 0.2 5.1
0.188 4.8 9-8208 132 40 20 0.51 0.187 4.8 70 4.8 55 170 0.60 0.2 5.1
0.25 6.4 9-8208 130 40 15 0.38 0.187 4.8 70 4.8 55 170 1.00 0.2 5.1
0.375 9.5 9-8208 130 40 10 0.25 0.187 4.8 70 4.8 55 170 NR NR NR
Type Torch: SL60QD With Shielded Tip Type Material: Aluminum
Type Plasma Gas: Air Type Secondary Gas: Single Gas Torch
Thickness Tip Output Amperage
Speed (Per
Minute)
Standoff
Plasma Gas
Press
Flow (CFH) Pierce
Pierce
Height
Inches
mm
(Cat.
No.)
Volts
(VDC)
(Amps) Inches Meters Inches mm psi* bar Plasma Total**
Delay
(Sec)
Inches mm
0.032 0.8 9-8208 116 40 220 5.59 0.187 4.8 70 4.8 55 170 0.00 0.2 5.1
0.051 1.3 9-8208 116 40 210 5.33 0.187 4.8 70 4.8 55 170 0.00 0.2 5.1
0.064 1.6 9-8208 118 40 180 4.57 0.187 4.8 70 4.8 55 170 0.10 0.2 5.1
0.079 2.0 9-8208 116 40 150 3.81 0.19 4.8 70 4.8 55 170 0.30 0.2 5.1
0.125 3.2 9-8208 130 40 75 1.91 0.19 4.8 70 4.8 55 170 0.40 0.2 5.1
0.188 4.8 9-8208 132 40 60 1.52 0.187 4.8 70 4.8 55 170 0.60 0.2 5.1
0.250 6.4 9-8208 134 40 28 0.71 0.187 4.8 70 4.8 55 170 1.00 0.2 5.1
0.375 9.5 9-8208 143 40 11 0.28 0.187 4.8 70 4.8 55 170 NR NR NR
Type Torch: SL60QD With Shielded Tip Type Material: Mild Steel
Type Plasma Gas: Air Type Secondary Gas: Single Gas Torch
Thickness Tip Output Amperage
Speed (Per
Minute)
Standoff
Plasma Gas
Press
Flow (CFH) Pierce
Pierce
Height
Inches
mm
(Cat. No.)
Volts
(VDC)
(Amps) Inches Meters Inches mm psi* bar Plasma Total**
Delay
(Sec)
Inches mm
0.060 1.5 9-8210 124 60 250 6.35 0.19 4.8 75 5.2 90 245 0.00 0.2 5.1
0.075 1.9 9-8210 126 60 237 6.02 0.19 4.8 75 5.2 90 245 0.10 0.2 5.1
0.120 3.0 9-8210 126 60 230 5.84 0.19 4.8 75 5.2 90 245 0.10 0.2 5.1
0.135 3.4 9-8210 128 60 142 3.61 0.19 4.8 75 5.2 90 245 0.10 0.2 5.1
0.188 4.8 9-8210 128 60 125 3.18 0.19 4.8 75 5.2 90 245 0.20 0.2 5.1
0.250 6.4 9-8210 123 60 80 2.03 0.19 4.8 75 5.2 90 245 0.30 0.2 5.1
0.375 9.5 9-8210 132 60 34 0.86 0.19 4.8 75 5.2 90 245 0.50 0.2 5.1
0.500 12.7 9-8210 137 60 23 0.58 0.19 4.8 75 5.2 90 245 0.75 0.2 5.1
0.625 15.9 9-8210 139 60 14 0.36 0.19 4.8 75 5.2 90 245 NR NR NR
0.750 19.1 9-8210 145 60 14 0.36 0.19 4.8 75 5.2 90 245 NR NR NR
1.000 25.4 9-8210 156 60 4 0.10 0.19 4.8 75 5.2 90 245 NR NR NR
