Thermal Dynamics Cutmaster 82 User Manual

cutmaster 82
Manual 0-4980 5-21 SERVICE
CAPACITOR PCB SIGNALS Signal Source-Destination
J1-1 Capacitor bank A+
J1-5 Capacitor bank A-
J2-1 Capacitor Bank B+
J2-5 Capacitor Bank B-
J3-1 +12 VDC M-C
J3-2 /460 Active low for 460VAC input M-C
J3-3 /230 Active low for 230VAC input M-C
MTH1,2 Capacitor bank A+
MTH3,4 Capacitor bank A-
MTH6,8 Capacitor Bank B+
MTH 5,7 Capacitor Bank B-

Thermal Dynamics Cutmaster 82 Specifications

General

Brand	Thermal Dynamics
Model	Cutmaster 82
Category	Welding System
Language	English
