Thermal Dynamics Drag-gun Service Manual

Introduction 10 Manual 0-2683
B. Input/Output Specifications
Model Hz
Input
Amps
RMS
Output
Amps
(DC)
Output
Voltage
(DC)
Duty
Cycle %
100/110V 50/60 25/24 12 85 30
120V *5022129530
120V 60 20 12 70 30
220V *5013128530
208/230V 60 10 12 78 30
* CE approved.
2.5 Dimensions
16.0 in
(406 mm)
9.0 in
(229 mm)
10.0 in.
(254 mm)
A-02004
Figure 2-1 Power Supply Dimensions
8 in (203 mm)
1.1 in (27 mm)
2.9 in
(75 mm)
8.9 in (226 mm)
1.1 in
(27 mm)
A-02385
180˚
70˚
Figure 2-2 Torch Dimensions
