PARTS LISTS 28 Manual 0-2683
5.3 Power Supply Replacement Parts
Item # Qty Description Ref. Catalog#
1 1 Transformer/Inductor (Incl. Chassis): T1/L1
DRAG-GUN 100V/50Hz 110V/60Hz 9-0023
DRAG-GUN 120V 50Hz 9-0024
DRAG-GUN 120V 60Hz 9-0001
DRAG-GUN 220V 50Hz 9-0037
DRAG-GUN 208/230 60Hz 9-0036
2 1 Cover (incl. Labels) 9-0002
3 1 Control PCB Assembly 9-0003
4 1 Capacitor: C13
DRAG-GUN 100V 50Hz/110V 60Hz, Capacitor AC 120UF, 180V 9-0004
DRAG-GUN 120V 50Hz, Capacitor AC 120UF, 180V 9-0004
DRAG-GUN 120V 60Hz, Capacitor AC 120UF, 180V 9-0004
DRAG-GUN 220V 50Hz, Capacitor AC, 60MFD, 370V 9-3924
DRAG-GUN 208/230 60Hz, Capacitor AC 60 MFD, 370V 9-3924
5 1 Wire Harness (Not Shown) 9-0005
6 1 Relay, DPST, -NO, 25A @ 250V K1 9-7508
7 1 Fan:
DRAG-GUN 100V/50Hz 110V/60Hz, Fan 115V 8-3209
DRAG-GUN 120V 50Hz, Fan 115V 8-3209
DRAG-GUN 120V 60Hz,Fan 115V 8-3209
DRAG-GUN 220V 50Hz, Fan 220V 9-7687
DRAG-GUN 208/230 60Hz, Fan 220V 9-7687
8 1 Compressor, Air, 12VDC, 0.5 CFM 9-0010
1 Compressor Disc Filter 9-7912
9 1 Resistor, 0.5ohm, 55 watt, 10%,3/16 Faston 9-0011
10 1 Resistor, 1Kohm, 55 watt, 5%,3/16 Faston 9-0012
11 1 Work Cable, 15 ft. (4.57 m) w/Red Handles 9-0013
12 1 Input Power Cable, 6.5 ft. min. (2 m):
DRAG-GUN 100V/50Hz 110V/60Hz, Power Cable, 14/3 w/molded plug 9-0052
DRAG-GUN 120V 50Hz, Power Cable, "CE", ** 9-0044
DRAG-GUN 120V 60Hz, Power Cable, 16/3 w/molded plug 9-0014
DRAG-GUN 220V 50Hz, Power Cable, "CE" ** 9-0044
DRAG-GUN 208/230 60Hz, Power Cable, 16/3 w/molded plug 9-0014
** Plug to be supplied by customer.
13 1 ON/OFF Switch:
DRAG-GUN Switch, DPST, 125V 15A w/RED NEON (non CSA) 9-0015
DRAG-GUN Switch, DPST, 22A, 125VAC, RED NEON (CSA) 9-0021
DRAG-GUN Switch, 16A, 250VAC, AMBER (or Red) NEON 9-0029
14 1 CD Transformer/Ferrite Core Assembly 9-0018
15 2 Bridge Rectifier 7-3345
16 1 Handle 9-8115
5.4 Options & Accessories (not shown)
Qty Description Catalog#
1 Circle Cutting Guide Kit 7-8910
1 Leads Wrap (installed under Handle) 9-7865
