Manual 0-2577 3 INSTALLATION
What's Included with
the Power Supply
Unpacking Procedure
Choosing a Location
CAUTION
CAUTION
NOTE
Included with each system is:
(1) Work Cable with Clamp (Attached)
(1) 14 AWG Single-Phase Input Power Cable (Attached)
(1) Operating Manual................................................Cat. No. 0-2577
(1) Spare Parts Kit - Includes:
(5) Standard Tips.................................................Cat. No. 9-4476
(3) Electrodes .......................................................Cat. No. 9-6006
(1) Gas Distributor ..............................................Cat. No. 9-6007
1. Unpack each item and remove all packing material.
2. Locate the packing list(s) and use the list to identify and
account for each item.
3. Inspect each item for possible shipping damage. If damage is
evident, contact your distributor and/or shipping company
before proceeding with system installation.
Select a clean, dry location with good ventilation and adequate
working space around all components.
The Power Supply is cooled by air flow through the front and
side panels. Air flow must not be obstructed. Provide at least 12
inches (300 mm) clearance on each side. Provide sufficient
clearance in front of the unit to allow access to front panel con-
trols (minimum 12 in or 300 mm).
Operation without proper air flow will inhibit proper cooling
and reduce duty cycle.
To prevent entry of cutting or other metal debris, the power
supply must not be operated in the vertical position. Operate the
power supply in the horizontal position or propped up by the
handle.
Review Important Safety Precautions (page 1) to be sure that the
selected location meets all safety requirements.
SECTION 2: INSTALLATION
2.1 UNPACKING AND CHOOSING A LOCATION
