INSTALLATION 4 Manual 0-2577
2.2 ELECTRICAL CONNECTIONS
WARNING
Power Requirements
NOTE
CAUTION
Disconnect primary power at the source before disassembling
the power suply, torch or torch leads.
The unit will operate from single phase 110V ±10%, 50/60 Hz.
The service should be fused for 15 amps.
Input power connections can be made directly to a properly
fused disconnect or by using a plug which conforms to the
recommended ratings.
The attached AC input power cable is three conductor, 14 AWG.
The primary power source, power cable, and plug all must
conform to local elecric code and recommended circuit
protection and wiring requirements.
