Thermal Dynamics ULTRA-CUT 100 User Manual

Manual No. 0-4819 3-9 INSTALLATION
F. Remove the Connections Cover
The primary power cable must be supplied by the end user and connected to the power supply.
Remove the connections cover on the rear of the Power Supply. Use caution when removing the panel; there is a
ground wire connected to the inside of the panel. Do not disconnect this wire.
Connections Cover
(Removed)
Connection Panel
Art # A-04797
