Manual No. 0-4819 3-1 INSTALLATION
SECTION 3: INSTALLATION
A. Installation Requirements
1. Electric Supply
The electrical supply network, the gas and water supply system must meet local safety standards. This
conformity shall be checked by qualified personnel.
CAUTION
Fuse and wire sizes are for reference only. The installation must conform to national and local codes for the type
and method of wire being used.
2. Gas Supply
The customer must supply all gases and pressure regulators. Gases must be of high quality. Pressure
regulators must be double-stage and installed as close as possible to the gas console. Contaminated gas
can cause one or more of the following problems:
• Reduced cutting speed
• Poor cut quality
• Poor cutting precision
• Reduced consumables life.
• Oil or grease contamination from compressed or bottled air can cause fires in conjunction with oxygen.
B. Cooling System Requirements
Coolant must be added to the system on installation. The amount required varies with torch leads length.
Thermal Dynamics recommends the use of its coolants 7-3580 and 7-3581 (for low temperatures).
Cat. Number and Mixture Mixture Protects To
7-3580 'Extra-Cool
TM
'
25 / 75 10° F / -12° C
7-3581 'Ultra-Cool
TM
'
50 / 50 -27° F / -33° C
7-3582 'Extreme Cool
TM
' Concentrate* -65° F / -51° C
Coolant Capabilities
* For mixing with D-I Cool
TM
7-3583
