Thermal Dynamics ULTRA-CUT 100 User Manual

Manual No. 0-4819 2-8 SPECIFICATIONS
F. XT
TM
-300 Torch Data (with Ultra-Cut
TM
300 Power Supply)
Ambient
Temperature
104° F
40° C
Duty Cycle 100% @ 300 Amps
Maximum Current 300 Amps
Voltage (V
peak
)500V
Arc Striking Voltage 10kV
Current
Up to 300 Amps, DC,
Straight Polarity
Plasma Gases:
Compressed Air, Oxygen,
Nitrogen, H35
Shield Gases:
Compressed Air, Oxygen,
Nitrogen, Water
Operating Pressure
125 psi ± 10 psi
8.6 bar ± 0.7 bar
Maximum Input Pressure 135 psi / 9.3 bar
Gas flow 10 - 300 scfh
XT
TM
-300 Torch Ratings
for use with Ultra-Cut 300 Power Supply
XT
TM
-300 Torch Gas Specification
s
G. Plasma Power Supply Used With:
• Thermal Dynamics Ultra-Cut
®
300

Thermal Dynamics ULTRA-CUT 100 Specifications

General

Brand	Thermal Dynamics
Model	ULTRA-CUT 100
Category	Welding System
Language	English
