Thermokon NOVOS 7 User Manual

Manual NOVOS und thanos EVO
Seite 38 Thermokon Sensortechnik GmbH
Shading 1 -
Slat adjustment
Selection, whether it is a shading
system with slat adjustment
0 = no
1 = yes
● ● 0 1 1 (yes) r / w 1617
Shading 1 –
Slat angle position min.
Setting the slat adjustment range
-90°
● ● -90 90 -80 r / w 1618
Shading 1 –
Slat angle position max.
Setting the blade adjustment range
+90°
● ● -90 90 80 r / w 1619
Shading 1 –
Slat angle position -
step width
Step width adjustment
1..90
● ● 1 90 20 r / w 1620
Shading 1 – Blind/Shutter
UP/DOWN - step width
Step width
1..100
● ● 1 100 10 r / w 1621
Shading 1 - Coordinate X
Starting from the upper left corner
of the graphic. 480 pixels for one-
sided graphics / 960 pixels for two-
sided graphics
0..960 Pixel
● 0 960 0 r / w 1622
Shading 1 - Coordinate Y
Starting from the upper left corner
of the graphic
0..800 Pixel
● 0 800 0 r / w 1623
Shading 2 - Description
Description see Shading 1 ● ● Blind 2 r / w 1624
Shading 2 - Icon
Description see Shading 1 ● ● 0 r / w 1636
Shading 2 –
Adjustment GUI
Description see Shading 1 ● ● 0 r / w 1637
Shading 2 -
Blade adjustment
Description see Shading 1 ● ● 1 (yes) r / w 1638
Shading 2 –
Slat angle position min.
Description see Shading 1 ● ● -80 r / w 1639
Shading 2 –
Slat angle position max.
Description see Shading 1 ● ● 80 r / w 1640
Shading 2 –
Slat angle position -
step width
Description see Shading 1 ● ● 20 r / w 1641
Shading 2 – Blind/Shutter
Up/Down - step width
Description see Shading 1 ● ● 10 r / w 1642
Shading 2 - Coordinate X
Description see Shading 1 ● 0 r / w 1643
Shading 2 - Coordinate Y
Description see Shading 1 ● 0 r / w 1644
Shading 3 - Description
Description see Shading 1 ● ● Blind 3 r / w 1645
Shading 3 - Icon
Description see Shading 1 ● ● 0 r / w 1657
Shading 3 -
Adjustment GUI
Description see Shading 1 ● ● 0 r / w 1658
Shading 3 -
Blade adjustment
Description see Shading 1 ● ● 1 (yes) r / w 1659
Shading 3 –
Slat angle position min.
Description see Shading 1 ● ● -80 r / w 1660
Shading 3 –
Slat angle position max.
Description see Shading 1 ● ● 80 r / w 1661
Shading 3 –
Slat angle position -
step width
Description see Shading 1 ● ● 20 r / w 1662
Shading 3 - Blind/Shutter
up/Down step width
Description see Shading 1 ● ● 10 r / w 1663
Shading 3 - Coordinate X
Description see Shading 1 ● 0 r / w 1664
Shading 3 - Coordinate Y
Description see Shading 1 ● 0 r / w 1665
