Manual NOVOS und thanos EVO
Seite 12 Thermokon Sensortechnik GmbH
4.2.5 Favorite buttons
The favorite buttons can be assigned with freely selectable functions. The names of the individual lights or scenes
can be defined individually. In addition to the up to eight lightings/lighting groups or scenes, functions such as
Presence (Presence/Absent), ECO (ON/OFF) and the Climate, Lighting, Blind, Scenes and Monitoring menus can be
assigned as favorite buttons (see Specification tab; "General" configuration data block).
NOVOS 7
NOVOS Touch / thanos EVO
Below the screen there are four configurable
capacitive touch buttons. The corresponding
symbols are displayed in the footer of the main
screen. These keys correspond to the parameters of
the favorite buttons 2 to 5. The push function of the
rotary/push encoder corresponds to the favorite
button 1. If the favorite button 1 is pressed in
standby or on the home screen, the respective
function is triggered and the corresponding symbol
is displayed on the home screen for approx. 3
seconds.
Favorite buttons NOVOS Touch / thanos EVO
If only one favorite button in the home screen is
required, address 1117 (button 1) must be written. If
several favorite buttons are needed (two to a
maximum of four), the data addresses 1118 to 1121
(keys 2 to 5) must be assigned the desired favorite
functions as well.
Configuration data block „General“
▪
Favorite button 1
▫ Data address 1117
▪
Favorite button 2
▫ Data address 1118
▪
Favorite button 3
▫ Data address 1119
▪
Favorite button 4
▫ Data address 1120
▪
Favorite button 5
▫ Data address 1121
0 = no function
1 = Light 1
2 = Light 2
3 = Light 3
4 = Light 4
5 = Light 5
6 = Light 6
7 = Light 7
8 = Light 8
9 = Scene 1
10 = Scene 2
11 = Scene 3
12 = Scene 4
13 = Scene 5
14 = Scene 6
15 = Scene 7
16 = Scene 8
17 = Occupancy
18 = Eco
19 = Menu Climate
20 = Menu Light
21 = Menu Blind
22 = Menu Scenes
23 = Menu Monitoring
24 = Menu Fan control (NOVOS 7)
