Manual NOVOS und thanos EVO
Thermokon Sensortechnik GmbH Seite 17
4.4 RGB(W) Color picker / Color temperature picker
Konfigurationsdatenblock „Licht“
▪
Lichtgruppe Verstellung
▫ Light 1; Data address 1416
▫ Light 2; Data address 1434
▫ Light 3; Data address 1452
▫ Light 4; Data address 1470
▫ Light 5; Data address 1488
▫ Light 6; Data address 1506
▫ Light 7; Data address 1424
▫ Light 8; Data address 1542
Slider = 0
Push button operation = 1
Push button operation (raw) = 2
RYB Color picker = 3
(color circle + dimmer slider)
Color temperature picker = 4
(color circle + dimmer slider)
▪
Limit values color temperature
▫ Min. light color 1; Data address 1547
▫ Max light color 1; Data address 1548
▫ Min. light color 2; Data address 1549
▫ Max light color 2; Data address 1550
▫ Min. light color 3; Data address 1551
▫ Max light color 3; Data address 1552
▫ Min. light color 4; Data address 1553
▫ Max light color 4; Data address 1554
▫ Min. light color 5; Data address 1555
▫ Max light color 5; Data address 1556
▫ Min. light color 6; Data address 1557
▫ Max light color 6; Data address 1558
▫ Min. light color 7; Data address 1559
▫ Max light color 7; Data address 1560
▫ Min. light color 8; Data address 1561
▫ Max light color 8; Data address 1562
Min. value 1000-6600K
Max. value 6600-15000K
RGB(W) Colorpicker
Whether classic RGB or RGBW lighting, the
Colorpicker makes it easy to choose any colour you
like and use it for lighting. NOVOS Touch determines
the colour value of a selected point on the colour
wheel and displays it in RGB(W) format. Up to 16
million light colours are thus possible
A dimmer slider is also available for the respective
lighting circuit.
Color temperature picker
Whether bright daylight or a warm lighting scenario,
any shade of white is possible with the colour
temperature picker. Limit values for the color
temperature can be configured.
