Manual NOVOS und thanos EVO
Thermokon Sensortechnik GmbH Seite 43
Parameter Description N3 N5 N7
Touch/
EVO
Min Max Default Access
Data
address
Unit of the measured value
°C
● ● ● ●
2010
Offset for compensation of external
influences
(Surface temperature, draught, etc.)
● ● ● ●
0
r / w
int16_t
2011
Measuring range lower limit
Min. value of the measuring range
must be within the sensor limitation
[Select measuring range]
● ● ● ●
0
r / w
int16_t
2012
Measuring range upper
limit
Max. value of the measuring range
must be within the sensor limitation
● ● ● ●
500
r / w
int16_t
2013
Select, whether the value should be
displayed in the monitoring menu
(Register – Measuring value
assignment see table p.25)
0 = No
● ●
1
r / w
uint16_t
2014
Colour visualization of the measured
value via TLF
(Traffic Light Function).
The colour thresholds can be
adjusted individually.
0 = not active
1 = active with TLF w/o 60 min. chart
2 = active w/o TLF with 60 min. chart
3 = active with TLF with 60 min chart
4 = active with HTLF w/o 60 min chart
5 = active with HTLF with 60 min
● ● ● ●
3
r / w
uint16_t
2015
Colour definition for the first range.
Range 1 begins with the lower
measuring range limit and ends with
threshold value 1-2.
0 = transparent
1 = white
2 = black
3 = red
4 = green
5 = blue
6 = yellow
7 = magenta
8 = turquoise
9 = orange
10 = Contrast colour (do not use for
TLF!)
● ● ● ●
3
r / w
uint16_t
2016
Colour definition for the second area.
Range 2 starts with threshold 1-2 and
ends with threshold 2-3.
See Range 1
● ● ● ●
6
r / w
uint16_t
2017
Colour definition for the third range.
Range 3 starts with threshold 2-3 and
ends with threshold 3-4.
See Range 1
● ● ● ●
4
r / w
uint16_t
2018
Colour definition for the fourth range.
Range 4 starts with threshold value 3-
4 and ends with threshold value 4-5.
See Range 1
● ● ● ●
6
r / w
uint16_t
2019
