Lubrication System (cont’d)
7 Remove the oil fill cap located in the engine rocker
arm cover. (fig. C3613) Add 7.5 liters (8qts) of 10W30
API classification SE / CD engine oil. Replace the fill cap
in the rocker arm cover.
7-3
C3613
C642
C3614
C3612
Engine oil fill cap
Engine oil level
dip stick location
Engine oil level dip stick markings
Check for leaks
9 Check the level of the engine oil. (fig. C3614) Add
oil as required to bring the oil to the top mark of the
engine oil dip stick. (fig. C642) Do not over fill.
Change the engine oil every 75 hours and the engine oil
filter every 150 hours.
8 Start the engine and check for leaks around the oil
filter and oil pan drain plug. (fig. C3612) Allow the
engine to operate for approximately 5 minutes and then
shut it off.
ENGINE MAINTENANCE 7.1
