1.2D Universal Joint Access
After removal of the operators seat, the U-joint service /
inspection panel can be accessed. (fig. C3453) Remove
the 2 bolts retaining the panel to the frame, push toward
the rear of the loader at the top of the panel, and pull the
panel forward and out by the bottom.
U-joint access panel retaining nuts
MAINTENANCE 8.1
C3453
Keep the rear door closed except for servicing. Make
sure the door is closed and latched before operating
the loader.
IMPORTANT
Locked
Unlocked
Door Handle
