REVUE THOMMEN AG
CH-4437 Waldenburg
AD20 Standby Altimeter
Page 15 of 72
07-Sep-2009 Document No: AD-INSOP-800 Revision: 1.6
1.1.2.3 Installation Kit
Part Number Quantity Description
AD20.XX.XXX.XX.X.XX 1 REVUE THOMMEN AD20 Standby Altimeter
AD-INSOP-800 1
REVUE THOMMEN AD20 Standby Altimeter
Installation and Operation Manual
AD-DDP-XXX 1 Declaration of Design and Performance
Table 1-6 Installation Kit
NOTE: As per ordered by the Installer.
1.1.3 Technical Specification
Characteristics Specifications
Primary Power 28 VDC
During startup max. 4.0 W / 140mA
Normal operation max. 1.7 W / 60mA
Emergency Power 28 VDC
Lighting power 5 VDC (opt. 28 VDC)
Physical Dimension
Height 56.13 mm (2.2 in)
Width 56.13 mm (2.2 in)
Length 179 mm (7.047 in)
Table 1-7 Technical Specification
