2.3.1.10 Digital Display
The following table shows the altitude indication and the baro setting on the display of the REVUE
THOMMEN AD20 Standby Altimeter:
The altitude display in feet is shown in the table below:
Measured Altitude [feet] LCD Indication [feet] Rem.
> 55,610 - - E r r 2)
10,000 10 000
1,000 01 000
100 0 100
10 010 1)
1 01 1)
0- - - 00
-100 - 0 100
-1,000 - 1 000
< -1,060 - - E r r 2)
Table 2-6 Digital Display in feet
The altitude display in meter is shown in the table below:
Measured Altitude [meter] LCD Indication [meter] Rem.
> 16,950 - - E r r 3)
10,000 10 000
1,000 01 000
100 0 100
10 010 1)
1 01 1)
0 - - - 00
-100 - 0 100
< -323 - - E r r 3)
Table 2-7 Digital Display in meter
