AD20 Standby Altimeter
Page 51 of 72
07-Sep-2009 Document No: AD-INSOP-800 Revision: 1.6
4.1.6.1.6 Label 217 (Static Pressure )
Label 217
(
Static Pressure
)
BIT
1 SAL LSB
2
3
4
5
6
7
8 SAL MSB
8 Bit SAL = 217 octal
9 SDI
10 SDI
Source / Destination Identifier
11 PAD
12 PAD
13 Value BNR LSB
14
15
16
17
Spare Bits
18
19
20
21
22
23
24
25
26
27
28
29 Value BNR MSB
Range:
64 inHg
Resolution:
0.000976 inHg
30 SSM
31 SSM
Sign Status Matrix
32 PARITY
Table 4-6 Label 217 (Static Pressure )
