Thommen AD20 - Appendices; APPENDIX I: Function Overview

REVUE THOMMEN AG
CH-4437 Waldenburg
AD20 Standby Altimeter
Page 67 of 72
07-Sep-2009 Document No: AD-INSOP-800 Revision: 1.6
6 Appendices
6.1 APPENDIX I: Function Overview
z = standard feature O = optional feature
Features Specification AD20
Basic Functions
Altitude Range - 1,000 ... 55,000 ft
z
Certification ETSO/TSO-C10b
z
RTCA/DO-178B, Level A
z
Baro Setting Knob
z
Baro Setting push to Standard Reset to 29.92 inHg / 1013.25 hPa
z
Unit Selection button inHg / hPa, ft / m
z
Test button
z
Lighting
Lighting color white
z
Power Supply
Primary power supply 28 VDC
z
Emergency Battery power supply Internal Battery O
Lighting power supply 5 VDC or 28 VDC
z
Inputs
TEST activation Discrete input
z
Battery activation Discrete input O
A/C Type selection Discrete input
z
Day/Night switch Discrete input
z
Metric Unit Selection Discrete input
z
