Thommen AD20 - 4.1.6.1.7 Label 234 (Baro correction hPa #1)

REVUE THOMMEN AG
CH-4437 Waldenburg
AD20 Standby Altimeter
Page 52 of 72
07-Sep-2009 Document No: AD-INSOP-800 Revision: 1.6
4.1.6.1.7 Label 234 (Baro correction hPa #1)
Label 234
(
Baro correction hPa #1
)
BIT
1 SAL LSB
2
3
4
5
6
7
8 SAL MSB
8 Bit SAL = 234 octal
9 SDI
10 SDI
Source / Destination Identifier
11 Value BCD LSB
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29 Value BCD MSB
Range:
700 to
1050 hPa
Resolution: 0.1 hPa
30 SSM
31 SSM
Value is in BCD Format so SSM
indicates if value is positive or negative:
SSM_PLUS = 0
SSM
_
MINUS = 3
32 PARITY
Table 4-7 Label 234 (Baro correction hPa #1)
