REVUE THOMMEN AG
CH-4437 Waldenburg
AD20 Standby Altimeter
Page 63 of 72
07-Sep-2009 Document No: AD-INSOP-800 Revision: 1.6
4.) The lighting curve number is increased by pushing the UNIT button.
Select the lighting curve number that shall be assigned to the selected lighting condition
number.
If the upper limit of lighting curve numbers is reached the lighting curve number rolls
over to the first lighting curve.
5.) Confirm the selected lighting curve by pushing the TEST button.
The selected lighting curve is stored and the next lighting condition number appears.
The currently configured lighting curve number for this lighting condition blinks.
6.) Repeat step 4.) and 5.) until the lighting curve for lighting condition number 4 is selected
and confirmed.
Note: The new setting is stored and used by the instrument after lighting condition 4 is
confirmed.
Cancel adjustments by pushing the TEST button for > 3 s during adjustment (restarts the
instrument). The previous settings will be used and all changes are disregarded.
