- 9 -
For linear throttle operation, the highlighted menu settings are required.
Auto Operation Settings Menu
Start/Stop Input (Floats, Transducer)
Fail Safe Float (On, Off)
Fail Safe Speed (Default = 2400 rpm)
Fail Safe Off Delay (Default = 0:00 seconds)
Auto Start Configuration Menu
Auto Start Delay (Default = 10 seconds)
Pre Heat Time (Default = 0 seconds)
Crank Time (Default = 10 seconds)
Crank Rest Time (Default = 10 seconds)
Warm Up Speed (Default = 800 rpm)
Warm Up Time (Default = 10 seconds)
Prime Speed (Default = 800 rpm)
Prime Time (Default = 0 seconds)
Cool Down Speed (Default = 650 rpm)
Cool Down Time (Default = 10 seconds)
Crank Cycles (Default = 5)
Fault Bypass Period (Default = 10 seconds)
Crank Hold Delay (Default = 0)
If any auto start configuration settings are not required (such as warm up speed), set the time to 0:00
seconds for that parameter.
