- 30 -
BATTERY RECHARGE MONITOR
A battery recharge monitoring system is available to start and run the engine to keep the battery
system charged. The battery recharge settings are available in the Battery Recharge Configuration
menu. The highlighted selections are required.
Battery Recharge Configuration
Recharge Monitor (Default = Off)
Recharge Voltage Selection (Default = 11.9 VDC)
Recharge Delay Selection (Default = 60 Sec)
Recharge Run Time Selection (Default = 15 Min)
Next Recharge Time Interval Selection (Default =
45 Min)
MODBUS CONFIGURATION
MODBUS (RS 485) can be used to communicate with a data collection system. Engine and Pump
information can be accessed through registers. Engine Start, Stop and Speed commands can also be
sent to the control panel by writing to coils and registers. Contact Thompson Pump for more
information.
MODBUS Mode (Default=Off) Slave
Baud Rate (9600) 19200, 38400
Communication Time Out (0:00)
