PRIOR TO STARTING ENGINE
Prior to starting the engine, fully complete the Parameter Configuration menu, select the
required START/STOP and THROTTLE settings. Reference the tables below to determine the
appropriate operating modes. Details on each setting are provided on the following pages.
PARAMETER CONFIGURATION
Critical features to pump operation are to be selected and configured in this menu. These items
include Fuel Level, Voltage Source, Hour meter, Transducer Settings (Application, Inlet Pressure
and Outlet Pressure) and Flow Rate. Choose the parameter to be configured by pressing the enter
button (placing brackets) and using the up and down arrow buttons. Once the correct parameter
appears press enter to select. Press the up arrow keys to configure the chosen parameter.
MANUAL OPERATION SETTINGS
AUTOMATIC OPERATION SETTINGS (Key in Auto Position)
Start/Stop Mode Available
Floats (single or dual)
Transducer
A fail safe float backup option is available for pressure and level modes should the
pressure or level transducer fail to operate.
Start/Stop Mode Available
Manual Key Start
Throttle Mode Available
Throttle Description
TSC Vernier
UP and DOWN via panel buttons
(set min and max speeds)
Multistate
UP and DOWN via panel buttons
(up to four separate operating speeds)
Throttle Mode Available
Throttle Description
Single Speed
Select warm up, prime, operating and cool down speeds
Linear
Engine speed adjusts between selected min and max speeds in relation
to selected min and max level or pressures
Target
Engine speed adjusts to maintain selected level or pressure
