PANEL TO ENGINE ECU COMMUNICATIONS
Communication between the panel and the engine ECU occurs over the two wire CAN bus (CAN High
wire and CAN Low wire). It is necessary that the panel and engine ECU settings be the same for the
following parameters:
1) Source Address
The source address is where the engine sends display and alarm data.
2) TSC1 Address
The TSC1 address is the address from which the engine ECU receives throttle commands from
the panel. If the panel and engine ECU do not have the same TSC1 address, the engine will not
throttle up or down.
3) Engine Type
The engine type is important for T4 operation. Selections are available for John Deere,
Caterpillar and Cummins engines. For other engines, select “Standard”.
The communication settings are available in the CAN Configuration menu shown below.
Engine Type (Default = Deere) See list below
TSC1 Address (Default = 3)
Source Address (Default = 44)
Engine Address (Default = 0) Available 0, 1, 2
Speed Transmit (Default = Off)
Temperature Transmit (Default = Off)
Oil Pressure Transmit (Default = Off)
Fuel Level Transmit (Default = On)
Voltage Transmit (Default = Off)
Hours Transmit (Default = Off)
Pump Parameters (Default = On)
Fault Transmit (Default = Active Only)
JDLINK Auto Accept (Default = Off)
To Next Page
