- 14 -
SLEEP MODE
To minimize current draw, the panel goes into a sleep mode two minutes after being set in auto
mode. In sleep mode, the display goes blank and the red lamp blinks once every ten seconds. The
engine ECU is also turned off.
Upon receiving a signal from a float or transducer, the panel wakes up, the display turns back on and
normal operation commences.
Pushing any of the four buttons wakes up the panel and turns the display on. It will return to sleep
mode after a two-minute period.
For service purposes, to keep engine ECU powered, access the menu system. The engine ECU remains
on when the menu system is active.
Red LED blinks
once every 10
seconds
To Next Page
