CLUTCH CONFIGURATION
The Clutch Configuration menu can be used to program two relays to open or close based on a
variety of criteria. You can mix and match Engage and Disengage criteria. If you select to engage on
Speed, you will need to set the actual speed you want it to close the relay upon reaching. Don’t forget
to assign a relay to Clutch 1 for the logic to run.
Heading
Default
Range
#1 Engage Trip
None
Engine Stopped/Engine Started/Speed
Above/Speed Below/Speed Crosses Above/Speed
Crosses Below/Load Above/Load Below/Coolant
Temp Above/Coolant Temp Below/Begin
Prime/Begin Warmup/Begin Ramp Up/Begin
Operate/Begin Ramp Down/Begin Cooldown/End
of Cooldown
#1 Engage Speed
1200 RPM
Min-Max Speeds
#1 Engage Load
0%
0-100%
#1 Engage Coolant Temp
150 degrees F
0-300 degrees F
#1 Engage Delay
0:00
0:00-5:00 minutes
#1 Engage Interval
0:00
0:00-5:00 minutes
#1 Release Trip
None
Same as Engage Trip 1
#1 Release Speed
800 RPM
Min-Max Speeds
#1 Release Load
0%
0-100%
#1 Release Coolant Temp
150 degrees F
0-300 degrees F
#1 Release Delay
0:00
0:00-5:00 minutes
#1 Release Interval
0:00
0:00-5:00 minutes
#2 Engage Trip
None
Same as Engage Trip 1
#2 Engage Speed
1200 RPM
Min-Max Speeds
#2 Engage Load
0%
0-100%
#2 Engage Coolant Temp
150 degrees F
0-300 degrees F
#2 Engage Delay
0:00
0:00-5:00 minutes
#2 Engage Interval
0:00
0:00-5:00 minutes
#2 Release Trip
None
Same as Engage Trip 1
#2 Release Speed
800 RPM
Min-Max Speeds
#2 Release Load
0%
0-100%
#2 Release Coolant Temp
150 degrees F
0-300 degrees F
#2 Release Delay
0:00
0:00-5:00 minutes
#2 Release Interval
0:00
0:00-5:00 minutes
