THOMPSON PUMP J1939 - Digital Function Monitoring; Digital Function Messages; Digital Function Delays

- 25 -
DIGITAL FUNCTION MONITORING
Off / Always / Run – Describes when the parameter will be monitored for alarm conditions. Run refers
to when the engine is running. Off disables the alarm conditions. Always enables the alarm constantly
regardless of engine state.
DIGITAL FUNCTION MESSAGES
A comprehensive list of common industry messages can be associated with the digital inputs to
identify what is connected to any particular input. For example, if you connected a Low Water level
switch to digital input 5, you can assign a message to digital input 5 of Low Water Level. This
message will be displayed when the input is active. If you need a label or message that is not
preloaded, there are four custom labels that can be created using the CI Station.
Low Water
Low Oil
Low Engine Oil
High Temperature
Low Pressure
Ext Shutdown
E-Stop
Remote E-Stop
High Pump Temp
Low Pump Oil
Low Fuel Level
Override Active
Polish Filter
Low Hydraulic Fluid
Vacuum High
High Hydraulic Temp
In Pressure Loss
Pipe Pressure Alarm
Low Coolant Level
Air Filter
Shutdown Override
High Wet Well
High Water Level
Fuel Leak
Custom 1
Custom 2
Custom 3
Custom 4
DIGITAL FUNCTION DELAYS
Alarm Delay – The time period after Sender Check Bypass, that the parameter must be on the alarm
condition before the alarm becomes latched.
