P6
CONNECTION
3.2 Connecting to TV with HDMI cable
Fig. 4
The TV set shall be connected with the receiver using a good quality HDMI 1.3 or
higher cable. This connection gives the highest possible quality.
3.3 Connecting to TV with SCART cable
Fig. 4
THT501 is also equipped with a SCART connector; alternatively, the TV set can be
connected to the receiver using a good quality SCART cable.
3.4 Connecting to TV with Cinch cable
Fig. 4
TV sets without SCART or HDMI input(s) can be connected to the receiver using
suitable cinch cables. Connect one end of the cable to the Audio L, R and VIDEO
connectors on the back of THT501. Connect the other end to the respective inputs
on your TV set.
3.5 Connecting to a Digital Audio Amplifier with S/PDIF
Fig. 5
By connecting your receiver to a digital amplifier or home theatre system, you can
enjoy the best possible sound quality and multi-channel audio (depending on
broadcast). Connect your Digital Audio Amplifier or home theatre system with a
suitable cinch cable to the S/PDIF connector on the back of the receiver.
3.6 Connecting to a Digital Audio Amplifier and TV using HDMI
Fig. 6
By connecting your receiver to the latest digital amplifiers or home theatre systems
with HDMI connections, you will enjoy the best possible sound quality and multi-
channel audio (depending on broadcast). Connect the HDMI output of the receiver
to an input of your amplifier, and then connect the HDMI output of the amplifier
to your TV set. Select the correct input on your amplifier to watch and listen
to programmes.
3.7 Connecting a USB storage device
Fig. 7
NOTE: We recommend the use of a hard disk drive USB 2.0 or higher for
recording and play back of TV events.
For proper functioning of Time Shift and recording functions, a fast USB device
(such as a hard disk drive) is needed. Interrupted playback or a distorted picture
during playback or Time Shift are indications for a low device speed. THOMSON
cannot guarantee proper functioning of recoding and or Time Shift functions with all
USB devices.
3.8 Connecting and using an infrared sensor
Fig. 7
