THOMSON TR-069 - Page 11

E-DOC-CTC-20071119-0003 v1.0
5
1| Introduction
 WT-140 “TR-069 data model for storage service enabled devices”: this document defines a
StorageService data model for a device that maintains a storage service, such as a Network Attached
Storage (NAS) device, as an extension of TR-069.
 PD-128 version 6 “Interoperability test plan for TR-069 plugfests”, June 2006: this document defines
TR-069 tests and their expected outcome. These tests are used during the TR-069 plugfests as tests to
perform. The DSL Forum regularly organizes TR-069 plugfest test events where all participating CPE
devices can test against all participating ACS servers. The document is also the de facto reference for
TR-069 testing by customers and ACS vendors.
Architecture
Following illustration shows the location of the specifications in the CWMP architecture:
Thomson firmware is interoperability tested with and by ACS partners.
ACS
DSLAM BRAS ACS
Access
Network
CPE
IP
Network
TR-069 CWMP (Am.1)
Provid
er
Helpde
sk
CPE
CPE
CPE
TR-064
LAN CPE Auto-Configuration
WT-135
S
TB Model
TR-104
VoIP Model
TR-098 (Am.1)
IGD Model
TR-111 CWMP
for home devices
TR-106 CWMP enabled
device model template
WT-140
Network Storage Model
