5| WAN Connections
5.3 Connection Information
PPP connection
To obtain information on the connection status, the assigned external IP address and forwarding entries, the
GetParameterValues RPC (message 13 in preceding illustration) contains following ParameterNames
arguments:
IP connection
To obtain information on the connection status, the assigned external IP address and the forwarding entries,
the GetParameterValues RPC (message 13 in preceding illustration) contains following ParameterNames
arguments:
Entry Value
1 InternetGatewayDevice.WANDevice.1.WANConnectionDevice.2.WANPPPConnection.1
2 InternetGatewayDevice.Layer3Forwarding.Forwarding
Entry Value
1 InternetGatewayDevice.WANDevice.1.WANConnectionDevice.2.WANIPConnection.1
2 InternetGatewayDevice.Layer3Forwarding.Forwarding
