THOMSON TR-069 - Forwarding Entries

E-DOC-CTC-20071119-0003 v1.0
66
5| WAN Connections
5.4 Forwarding Entries
PPP connection
For example, following parameter values can be used:
 Creating an entry: to add a forwarding entry, the AddObject RPC (message 15 in preceding illustration)
contains for the ObjectName argument the value
“InternetGatewayDevice.Layer3Forwarding.Forwarding.”.
The AddObjectResponse (message 17 in preceding illustration) contains for the InstanceNumber
argument for example value “3“.
 Configuring the entry: the SetParameterValues RPC (message 18 in preceding illustration) contains
following name-value pairs in its ParameterList argument, for example to add a default route:
IP connection
For example, following parameter values can be used:
 Creating an entry: to add a forwarding entry, the AddObject RPC (message 15 in preceding illustration)
contains for the ObjectName argument the value
“InternetGatewayDevice.Layer3Forwarding.Forwarding.”.
The AddObjectResponse (message 17 in preceding illustration) contains for the InstanceNumber
argument for example value “3“.
 Configuring the entry: the SetParameterValues RPC (message 18 in preceding illustration) contains
following name-value pairs in its ParameterList argument, for example to add a default route:
Name Value
InternetGatewayDevice.Layer3Forwarding.Forwarding.3.DestIPAddres
s
0.0.0.0
InternetGatewayDevice.Layer3Forwarding.Forwarding.3.
DestSubnetMask
0.0.0.0
InternetGatewayDevice.Layer3Forwarding.Forwarding.3.
Interface
IGD.WANDevice.1.
WANConnectionDevice.2.
WANPPPConnection.1
InternetGatewayDevice.Layer3Forwarding.Forwarding.3.
ForwardingMetric
1
InternetGatewayDevice.Layer3Forwarding.Forwarding.3.
GatewayIPAddress
<ipaddress_Interface>
The parameters DestIPAddress, Interface and GatewayIPAddress are mandatory. This means
that these parameters must be set before the Forwarding object is internally created.
Name Value
InternetGatewayDevice.Layer3Forwarding.Forwarding.3.DestIPAddres
s
0.0.0.0
InternetGatewayDevice.Layer3Forwarding.Forwarding.3.DestSubnet
Mask
0.0.0.0
