5| WAN Connections
5.1 WAN Connection Device
WAN connection device
A WAN connection device can be created and configured as follows:
 Creating a WAN connection device: the AddObject RPC (message 1 in preceding illustration) contains for
the ObjectName argument the value “InternetGatewayDevice.WANDevice.1.WANConnectionDevice.”.
The AddObjectResponse (message 3 in preceding illustration) contains for the InstanceNumber
argument for example value “2“.
 Configuring the WAN connection device: to create and configure the ATM PVC, the SetParameterValues
RPC (message 4 in preceding illustration) contains following name-value pairs in its ParameterList
argument:
Link type value
Following table shows the link type of a specific WAN connection:
Name Value
InternetGatewayDevice.WANDevice.1.WANConnectionDevice.2.
WANDSLLinkConfig.LinkType
EoA, PPPoA or IPoA
See “ Link type value”.
InternetGatewayDevice.WANDevice.1.WANConnectionDevice.2.
WANDSLLinkConfig.DestinationAddress
8/35 (VP/VC)
InternetGatewayDevice.WANDevice.1.WANConnectionDevice.2.
WANDSLLinkConfig.ATMEncapsulation
LLC or VCMUX
InternetGatewayDevice.WANDevice.1.WANConnectionDevice.2.
WANDSLLinkConfig.Enable
1
WAN connection Link type
PPPoE EoA
IP EoA
PPPoA PPPoA
IPoA IPoA
